TECHNICAL SPECIFICATIONS FOR SOLAR INVERTER SYSTEM (OFF GRID TYPE)
| S.No. | ||||||||
| 1) | Rating | 1 KVA | 2 KVA | 3 KVA | 5 KVA | |||
| 2) | DC VOLT | 24 or 48 VDC | 48 VDC / 72 VDC / 96 VDC | 96 VDC/120 VDC / 144 VDC | ||||
| 3) | I/P RANGE | 20 VDC – 60 VDC | 40 VDC – 100VDC | 80 VDC – 200 VDC | ||||
| 4) | DC AC EFF | > 90% | ||||||
| 5) | O/P WAVEFORM | Pure Sine Wave | ||||||
| 6) | THD | <3% for Linear Load, 5% for Nonlinear Load | ||||||
| 7) | LOAD PF | 0.8 to Unity | ||||||
| 8) | CREST FACTOR | 3 : 1 | ||||||
| 9) | METERING | LCD Display for : Input DC volt ; Output volt AC ; Output Current ; Output frequency ; DC Current; KWH | ||||||
| 10) | Indication | DC ON ; DC Under ; Dc Over ; Overload ; Load on mains ;Mains Charger on | ||||||
| 11) | PROTECTIONS | Battery low / dc under ; DC Over ; Over load / Short circuit ; Manual C / O to mains charger incase of solar not available ; Input reverse polarity blocking diode | ||||||
| 12) | FEATURES | Inbuilt high frequency SMPS type MPPT charger ; Inbuilt galvanic isolation ; MPPT eff –93% | ||||||
| 13) | Indications for MPPT | Solar ON ; Charging ON | ||||||
| 14) | SWITCH GEARS | a) Input MCB for solar, Battery, MPPT ; b) Output MCB for AC | ||||||
| 15) | Fuses | Fuse Protection at DC and AC side | ||||||
| 16) | IEC / BIS | Product Meets IEC / BIS Standards | ||||||
| 1000 W | 2000 W | 3000 W | 5000 W | |||||
| 17) | Space required for Polycrystalline Solar Panel | 110 Sq. ft | 220 Sq. ft | 330 Sq. ft | 550 Sq. ft | |||
| 18) | Space required for Thin film Solar Panel | 200 Sq. ft | 440 Sq. ft | 600 Sq. ft | 1000 Sq. ft | |||
| 19) | Overall Dimensions of Solar charger controlled Inverter (in mm) | D = 390 mm W = 240 mm H = 390 mm | D = 450 mm W = 180 mm H = 480 mm | D = 450 mm W = 180 mm H = 480 mm | D = 615 mm W = 400 mm H = 620 mm | |||
| Weight | 30 Kg | 40Kg | 50 Kg | 60 Kg | ||||
