High reliability design
- Double Conversion on-line design, which make the output a pure sine wave source with tracking frequency, phase—lock- and voltage regulation, low distortion and without power fluctuation interference, providing the load with more comprehensive protection.
Strong protection for load
- Built-in isolation transformer, strong anti-interference ability, provides more comprehensive protection.
Wide input range
- Wide input voltage range up to 304-456VAC, avoid frequently switching to battery mode, which adapt to the areas with harsh environment.
- Wide input frequency range, ensure all types of fuel generators connected work stable.
User-friendly network management
- Communication with computer can be realized by RS232 with corresponding monitoring software. The various parameters can be shown on the communication interface.
- External SNMP adapter. The UPS with remote network management capability can provide real-time data for communication and management through a variety of network management systems.
Comprehensive and reliable protection
- Self-diagnosis function before start-up, avoid the risks that the failure may lead to.
- The multi-protection such as overload, short-circuit, over-temperature, battery under voltage, battery over-charge and so on greatly ensure the system stability and reliability.
REAR PANEL
- RS232 port
- Input breaker
- FAN
- Connection Box
- Entrance Hole
- Active wheel
Optimization of high-performance battery
- Adapt intelligent battery management(ABM) technology,thus extending battery life and reducing battery maintenance times.
- Advanced floating switching and charging technology maximize the activation of the battery, thus saves the charging time and extends the battery life.
